Body TypeMade of AISI 321 (DIN 1.4541) quality stainless steel material, having a filling manhole or cleaning manhole according to EN 14025 s tandard on each compartment separated by breakwaters fitted in accordance with EN 14025 standard for ease of cleaning, with sloping design to prevent liquids from staying in the tank,conforms to EN 14025 standard, with cylindrical section body with L4BH ADR code
ChassisMade of high quality and high strength S355JR steel, in compliance with Standard ISO 1726-2. Made of two welded longitudinal beams i n "I" form with cross beams at needed distances. Reinforced with Galvanized protection with Kässbohrer expertise
Brake SystemThere is a dual-circuit electro-pneumatic braking system with WABCO EBS 4S / 3M antiblocking system suitable for UN ECE R13 regulati on and an integrated RSS electronic stability control system in the braking system
Tyre Size385/65 R 22.5
Axle SpecDrum brake axle
Electric SystemASPÖCK branded lighting system
Number Of Compartments1 compartment
Manhole Number1 unit
Filling FunnelNo funnel in front of the suction line at the top rear of the tank
Hose CarrierOpen-top large (high) box type 5 meter hose holder made of aluminum
