ChassisTwo I type (double T type) extruded profiles made of special alloy aluminum which provides high quality and high strength and having special strength increased. It is a specially designed aluminum cross connection chassis
Brake SystemThere is a dual-circuit electro-pneumatic braking system with WABCO EBS 4S / 2M antiblocking system suitable for UN ECE R13 regulati on and an integrated RSS electronic stability control system in the braking system
Tyre Size385/65 R 22.5
AxlesBPW air suspension and disc brake axle with 3 x 9 tons capacity
Electric SystemASPÖCK branded lighting system
Body TypeEquipped with lifting aluminum cylindrical tank, full-length reinforcement profiles on the right and left of the tank and a DN700 discharging cone at the rear
Manhole Number3 x DN450 Pressure Type Domes
Discharge Cone DimensionEquipped with a stainless electropolished discharge cone reducing the discharging diameter from 700 mm to 200 mm
Hose Carrier2 x DN200, 5m plastic hose holder with side and rear covers
