ChassisTwo extruded box profiles made of special alloy aluminum which provides high quality and high strength, special extruded box profiles made of aluminum, and specially designed aluminum crossover connection, conforming to ISO 1726 norms
Brake SystemThere is a dual-circuit electro-pneumatic braking system with WABCO EBS 4S / 2M antiblocking system suitable for UN ECE R13 regulati on and an integrated RSS electronic stability control system in the braking system
Tyre Size385/65 R 22.5
AxlesBPW air suspension and disc brake axle with 3 x 9 tons capacity
Electric SystemASPÖCK lightning installation with 24 V LED side position lamp and 2x7 and 1x15-pin sockets, in compliance with Regulation UN ECE R 48 and ADR Legislation
Tank Volume DistributionPartition volumes, respectively: 1 - 6400 l / 2 - 5700 l / 3 - 6000 l / 4 - 10 000 l / 5 - 8000 l
Number Of Compartments5
Filling And Discharging SystemThe filling and discharge system is suitable for top and bottom filling
